Series 0i Mate - MB Operators manual Page 384

Operators manual

Page of 842

/ 842

PROGRAMMING

19. HIGH SPEED CUTTING

FUNCTIONS

B–63864EN/03

360

(1) Linear acceleration / deceleration before interpolation

Meaning of parameter Parameter No.

Normal Advanced

preview

control

advanced

preview

Switch of acceleration /

deceleration type

FWB/1602#0 –

Maximum machining speed during lin-

ear Acceleration / deceleration before

Interpolation

1630 1770

Time used to reach the maximum ma-

chining speed during linear accelera-

tion / deceleration before interpolation

1631 1771

Feedrate when overtravel alarm has

occurred

1784

(2) Automatic corner deceleration

Meaning of parameter Parameter No.

Normal Advanced

preview

control

advanced

preview

Switch of automatic corner deceleration

type

CSD/1602#4 –

Minimum feedrate (controlled by angle) 1778 1777 –

Critical angle (controlled by angle) 1740 1779 –

Allowable feedrate difference

(controlled by feedrate difference)

1780 –

Allowable feedrate difference for each

axis (controlled by feedrate difference)

1783

(3) Feedrate clamp based on acceleration

Meaning of parameter Parameter No.

Normal Advanced

preview

control

advanced

preview

Allowable acceleration determination – 1785

D Normal / Advanced

preview control / AI

advanced preview

control parameter

number correspondence
