APPENDIX

B–63864EN/03

G. ALARM LIST

799

No. DescriptionFaulty location and remedy

SPM

indica-

tion(*1)

Message

7n26 SPN_n_ : DISCONNECT

C–VELO DE-

TECT

26 1 Replace the cable.

2Re–adjust the pre–amplifier.

The signal amplitude of the detec-

tion signal (connector JY2) on the

Cs contour control motor side is ab-

normal.

(Unconnected cable, adjustment er-

ror, etc.)

7n27 SPN_n_ : DISCONNECT

POS–CODER

27 1 Replace the cable.

2Re–adjust the BZ sensor signal.

1 The spindle position coder (con-

nector JY4) signal is abnormal.

2 The signal amplitude (connector

JY2) of the MZ or BZ sensor is

abnormal.

(Unconnected cable, adjustment

error, etc.)

7n28 SPN_n_ : DISCONNECT

C–POS DE-

TECT

28 1 Replace the cable

2Re–adjust the pre–amplifier.

The position detection signal (con-

nector JY5) for Cs contour control is

abnormal.

(Unconnected cable, adjustment er-

ror, etc.)

7n29 SPN_n_ : SHORTTIME

OVERLOAD

29 Check and correct the load status. Excessive load has been applied

continuously for a certain period of

time. (This alarm is issued also

when the motor shaft has been

locked in the excitation state.)

7n30 SPN_n_ : OVERCUR-

RENT POW

CIRCUIT

30 Check and correct the power supply

voltage.

Overcurrent is detected in PSM

main circuit input. (PSM alarm in-

dication: 1)

Unbalanced power supply.

PSM selection error (The maximum

PSM output specification is exceed-

ed.)

7n31 SPN_n_ : MOTOR LOCK

OR V–SIG LOS

31 1 Check and correct the load sta-

tus.

2 Replace the motor sensor cable

(JY2 or JY5).

The motor cannot rotate at a speci-

fied speed. (A level not exceeding

the SST level for the rotation com-

mand has existed continuously.)

Abnormality in the speed detection

signal.

7n32 SPN_n_ : RAM FAULT

SERIAL LSI

32 Replace the SPM control printed cir-

cuit board.

Abnormality in an SPM control cir-

cuit component is detected. (The

LSI device for serial transfer is ab-

normal.)

7n33 SPN_n_ : SHORTAGE

POWER

CHARGE

33 1 Check and correct the power

supply voltage.

2 Replace the PSM unit.

Charging of direct current power

supply voltage in the power circuit

section is insufficient when the mag-

netic contractor in the amplifier is

turned on (such as open phase and

defective charging resistor).

7n34 SPN_n_ : PARAMETER

SETTING ER-

ROR

34 Correct a parameter value accord-

ing to the manual.

If the parameter number is un-

known, connect the spindle check

board, and check the indicated pa-

rameter.

Parameter data exceeding the al-

lowable limit is set.

7n35 SPN_n_ : EX SETTING

GEAR RATIO

35 Correct the value according to the

parameter manual.

Gear ratio data exceeding the allow-

able limit is set.
