B-63864EN/03 MANUAL GUIDE 0i 1.MANUAL GUIDE 0i

- 709 -

1.5.2 Detail of Contour Figure Data

This chapter describes the details of the contour figure data, which is

entered on the contour figure data screen.

Details of the contour figure data for the start point and line are given

in the previous chapter. Refer to the explanation as necessary.

1.5.2.1 Arc

Data item Comment

END POINT X X coordinate of an arc end point

END POINT Y Y coordinate of an arc end point

RADIUS R Radius of an arc, but plus value only

CENTER I X coordinate of an arc center

CENTER J Y coordinate of an arc center

TOUCH STATE Select from the following soft-key menu whether

tangential or not between neighbor figure.

[NO] : Not tangential

[LAST] :Tangential with the preceding figure

FEEDRATE Feedrate under G01 selecting

NOTE

The feedrate data item is displayed when parameter

No.9341#3(FCD) is set to 1.

[AUX.] : Call auxiliary calculating screen. The result of it will be

set into start point coordinate data.

[OK] : Fix arc figure data and store into memory.

[CANCEL] : Cancel arc figure data entering and return to the

contour program list screen.

1.5.2.2 Corner R

Data item Comment

RADIUS R Radius of a corner R, but plus value only

FEEDRATE Feedrate

NOTE

The feedrate data item is displayed when parameter

No.9341#3(FCD) is set to 1.

[OK] : Fix corner R figure data and store into memory.

[CANCEL] : Cancel corner R figure data entering and return to the

contour program list screen.
