1.MANUAL GUIDE 0i MANUAL GUIDE 0i B-63864EN/03

- 698 -

1.4.2.8 Figure block of Groove machining

Radial line grooves - Fixed figure : G1223

Data item Comment

U DISTANCE BETWEEN

CENTERS

Distance between 2 circle centers at the each end of

groove

D GROOVE WIDTH Width of the groove

L DEPTH Depth of groove, distance from workpiece surface to

the bottom of pocket, usually negative value

E GROOVE ANGLE Angle of the groove

A ANGLE Angle of the 1st radial groove center point from X-

axis

H CENTER POINT (X-AXIS) X-coordinate of center point of the plural radial

grooves

V CENTER POINT (Y-AXIS) Y-coordinate of center point of the plural radial

grooves

R GROOVE POSITION

RADIUS

Radius of arc on which plural radial grooves are

positioned

B REFERENCE POSITION Z-coordinate of the workpiece surface

C PITCH ANGLE Center angle between 2 radial grooves

M NUMBER OF GROOVE Number of radial grooves

NOTE

1 Position of a 1st radial groove is calculated from

CENTER POINT, GROOVE POSITION RADIUS

and ANGLE, so these data must be entered always.

2 If only one groove is necessary, PITCH ANGLE

need not be entered.
