PROGRAMMING

19. HIGH SPEED CUTTING

FUNCTIONS

B–63864EN/03

346

This function is designed for high–speed precise machining. With this

function, the delay due to acceleration/deceleration and the delay in the

servo system which increase as the feedrate becomes higher can be

suppressed.

The tool can then follow specified values accurately and errors in the

machining profile can be reduced.

This function becomes effective when advanced preview control mode is

entered.

For details, refer to the relevant manual published by the machine tool

builder.

P1 : Turn on advanced preview control mode.

P0 : Turn off advanced preview control mode.

G08 P_

In advanced preview control mode, the following functions are available:

(1) Linear acceleration/deceleration before interpolation

(2) Automatic corner deceleration function

For details on the above functions, see the Connection Manual (Function)

(B–63833EN–1). Each function, specific parameters are provided.

Advanced preview control mode is canceled by reset.

Specify G08 code only in a block.

In the advanced preview control mode, the functions listed below can be

specified.

NOTE

To use a function other than the following optional functions,

turn the advanced preview control mode off, specify the

desired function, then turn the mode on again.

⋅ Single direction positioning

⋅ Polar coordinate command

⋅ Helical interpolation

⋅ Rigid tapping

(Bit 5 (G8S) of parameter No. 1602 can be set to also use this function

in the advanced preview control mode. The serial spindle parameters

must also be set.)

⋅ Program restart

⋅ External deceleration

⋅ Simple synchronous control

⋅ Sequence number comparison and stop

19.2

ADVANCED PREVIEW

CONTROL (G08)

Format

Explanations

D Available functions

D Reset

Limitations

D G08 command

D Functions that can be

specified
