Series 0i Mate - MB Operators manual Page 461

Operators manual

Page of 842

/ 842

OPERATION

B–63864EN/03

4. AUTOMATIC OPERATION

437

PROGRAM O0001 N00020

N020 X100.0 Z100.0 (DNC–PROG) ;

N030 X200.0 Z200.0 ;

N040 X300.0 Z300.0 ;

N050 X400.0 Z400.0 ;

N060 X500.0 Z500.0 ;

N070 X600.0 Z600.0 ;

N080 X700.0 Z400.0 ;

N090 X800.0 Z400.0 ;

N100 x900.0 z400.0 ;

N110 x1000.0 z1000.0 ;

N120 x800.0 z800.0 ;

RMT STRT MTN *** *** 21:20:05

[ PRGRM ] [ CHECK ] [ ] [ ] [ (OPRT) ]

D Program screen

Seven soft key type

During DNC operation, the program currently being executed is

displayed on the program check screen and program screen.

The number of displayed program blocks depends on the program being

executed.

Any comment enclosed between a control–out mark “(” and control–in

mark “)” within a block is also displayed.

D During DNC operation, subprograms stored in memory can be called.

D During DNC operation, macro programs stored in memory can be

called.

In program display, no more than 256 characters can be displayed.

Accordingly, character display may be truncated in the middle of a block.

In DNC operation, M198 cannot be executed. If M198 is executed, P/S

alarm No. 210 is issued.

In DNC operation, custom macros can be specified, but no repeat

instruction and branch instruction can be programmed. If a repeat

instruction or branch instruction is executed, P/S alarm No. 123 is issued.

When reserved words (such as IF, WHILE, COS, and NE) used with

custom macros in DNC operation are displayed during program display,

a blank is inserted between adjacent characters.

Example

[During DNC operation]

#102=SIN[#100] ; → #102 = S I N[#100] ;

IF[#100NE0]GOTO5 ; → I F[#100NE0] G O T O 5 ;

Explanations

Limitations

D Limit on number of

characters

D M198 (command for

calling a program from

within an external

input/output unit)

D Custom macro
