Series 0i Mate - MB Operators manual Page 385

Operators manual

Page of 842

/ 842

PROGRAMMING

B–63864EN/03

19. HIGH SPEED CUTTING

FUNCTIONS

361

(4) Feedrate clamp based on arc radius

Meaning of parameter Parameter No.

Normal Advanced

preview

control

advanced

preview

Arc radius value corresponding to a

maximum feedrate

1731

Maximum feedrate for arc radius R 1730

Minimum value (RVmin) 1732

(5) Others

Meaning of parameter Parameter No.

Normal Advanced

preview

control

advanced

preview

Accuracy of radius error in circular

Interpolation

PCIR1/3403#0 –

Maximum cutting feedrate 1422 1431 1422

Maximum cutting feedrate for each

axis

1430 1432

Rapid traverse type LRP/1401#1 AIR/7054#1

LRP/1401#1

Time constant for bell–shaped accel-

eration / deceleration in rapid traverse

for each axis

1621 RBL/1603#6

1621

No Message Contents

5110 IMPROPER G–CODE

(G05.1 Q1 MODE)

A G–code which can not be used in the AI

advanced preview control mode is specified.

5111 IMPROPER MODAL

G–CODE (G05.1 Q1)

When the AI advanced preview control mode

is specified, a modal G–code is not correct.

5112 G08 CAN NOT BE

COMMANDED

The look–ahead control (G08) is specified

during the AI advanced preview control mode.

5114 NOT STOP

POSITION

(G05.1 Q1)

The axis does not return to the coordinate at

stop when the program restarts after the

manual intervention.

5156 ILLEGAL AXIS

OPERATION (AICC)

The control axis select signals (PMC axis

control) are changed during the AI advanced

preview control mode.

5157 PARAMETER ZERO

(AICC)

The maximum cutting feedrate ( parameter

No.1422 or No.1432 ) is 0.

The acceleration / deceleration setting ( pa-

rameter No.1770 or No.1771 ) is 0.

D Alarm
