1.MANUAL GUIDE 0i MANUAL GUIDE 0i B-63864EN/03

- 692 -

1.4.2.4 Figure block of Face machining

Square - Fixed figure : G1220

Data item Comment

H CENTER POINT (X-AXIS) Center point X-coordinate of the square

V CENTER POINT (Y-AXIS) Center point Y-coordinate of the square

U LENGTH ALONG TO THE

X-AXIS

Length of square side along X-axis

W LENGTH ALONG TO THE

Y-AXIS

Length of square side along Y-axis

B REFERENCE POSITION Z-coordinate of the workpiece surface

L DEPTH Not used in facing, so need not enter

A ANGLE Angle from X-axis

R CORNER RADIUS Radius of each corner of the square

NOTE

It is not necessary to enter the DEPTH and

CORNER RADIUS data item.

Circle - Fixed figure : G1221

Data item Comment

H CENTER POINT (X-AXIS) Center point X-coordinate of the circle

V CENTER POINT (Y-AXIS) Center point Y-coordinate of the circle

R RADIUS Radius of the circle

B REFERENCE POSITION Z-coordinate of the workpiece surface

L DEPTH Not used in facing, so need not enter

NOTE

It is not necessary to enter the DEPTH data item.
