PROGRAMMING

19. HIGH SPEED CUTTING

FUNCTIONS

B–63864EN/03

362

The model data when G05.1 P1 is specified should be as follows. If these

conditions are not filled, the P/S alarm No.5111 occurs.

G code Meaning

G00

G01

G02

G03

Positioning

Linear interpolation

Circular interpolation / Helical interpolation (CW)

Circular interpolation / Helical interpolation (CCW)

G25 Spindle speed fluctuation detection off

G40 Cutter compensation cancel

G49 Tool length compensation cancel

G50 Scaling cancel

G50.1 Programmable mirror image cancel

G64 Cutting mode

G67 Macro modal call cancel

G69 Coordinate system rotation cancel

G80 Canned cycle cancel

G94 Feed per minute

G97 Constant surface speed control cancel

NOTE

1 It is possible to specify the advanced preview control (G08

P1).

2 The deceleration of the axis is started when the total travel

of the axis in the blocks read in advance is less than the

distance required to decelerate the axis from the current

feedrate. When the total travel of the axis in the blocks read

in advance increases at the end of deceleration, the axis is

accelerated. When blocks specifying a short travel are

specified in succession, the axis may be decelerated, then

accelerated, then decelerated, and so on, resulting in an

unstable feedrate. In such a case, specify a smaller feedrate.

3 When the dryrun signal changes from 0 to 1 or from 1 to 0

during the axis movement, the feedrate accelerates or

decelerates to the commanded velocity without the

deceleration to 0.

4 When a block without movement or one–shot G–code such

as G04 is specified in the AI advanced preview control

mode, the deceleration stop is done at the previous block.

5 In case of using the acceleration / deceleration after cutting

feed interpolation, please use linear type or bell–shaped

type. It is not possible to use exponential type.

6 During changing to the AI advanced preview control mode,

the manual handle interruption becomes ineffective.

Limitations

D Conditions to enter AI

advanced preview

control mode
