Series 0i Mate - MB Operators manual Page 383

Operators manual
PROGRAMMING
B–63864EN/03
19. HIGH SPEED CUTTING
FUNCTIONS
359
Other functions f : Can be specified. : Cannot be specified.
Name Function
Cycle start/feed hold f
Dry run f
Single block f
Sequence number comparison
and stop
f
Program restart f For the time constant for acceleration/decelera-
tion during movement to the restart position,
the following parameters are used:
When exponential acceleration/deceleration is
used: Parameter Nos. 1624 and 1625
When linear/bell–shaped acceleration/decel-
eration is used: Parameter No. 1622
To set the acceleration/deceleration type, use
bits 0 and 1 of parameter No. 1610.
Rigid tapping return
Macro executor
(execution macro)
MDI operation f
Manual intervention f
NOTE
The multi blocks look ahead is stopped.
