1.MANUAL GUIDE 0i MANUAL GUIDE 0i B-63864EN/03
- 732 -
1.5.5 Others
1.5.5.1 Calculation of Inputting Data
Data can be entered for those items on the contour programming
screen by using pocket calculator type calculation, as follows.
Addition :
10+10
[INPUT] → 20
Subtraction :
10-10
[INPUT] → 0
To subtract from an entered item (10, for example):
-
→ - → 1 [INPUT] → 9
Multiplication :
10*10
[INPUT] → 100
Division :
10/10
[INPUT] → 1
SIN :
S30
[INPUT] → 0.5
COS :
C60
[INPUT] → 0.5
TAN :
T45
[INPUT] → 1
Square root :
R9
[INPUT] → 3
NOTE
1 For + - * /, more than two terms cannot be handled
at once. The third and subsequent terms are
neglected. So, 1 + 2 + 3 will be calculated as 1 +2.
2 The calculation of SIN, COS, TAN and Square root
can be done as only independent calculations. The
second and subsequent terms, if specified, will be
neglected. C60 + S60 will be calculated as C60 only.
Calculation based on previously input data is also
possible.
