B-63864EN/03 MANUAL GUIDE 0i 1.MANUAL GUIDE 0i

- 689 -

Square - Hole pattern : G1214

Data item Comment

B REFERENCE POSITION Z-coordinate of the workpiece surface

L DEPTH Hole depth (usually negative value)

H START POINT (X-AXIS) Start point X-coordinate of the 1st side (1st hole

point)

V START POINT (Y-AXIS) Start point Y-coordinate of the 1st side (1st hole

point)

U LENGTH ALONG TO THE

1ST SIDE

Length along to the 1st side

W LENGTH ALONG TO THE

2ND SIDE

Length along to the 2nd side

I NUMBER OF HOLE

ALONG TO THE 1ST SIDE

Number of holes along to the 1st side

J NUMBER OF HOLE

ALONG TO THE 2ND

SIDE

Number of holes along to the 2nd side

K ANGLE OF THE 1ST SIDE Angle of the 1st side

M ANGLE OF THE 2ND SIDE Angle of the 2nd side

A OMITTING POINT-1 Hole number of 1st machining omitting hole

C OMITTING POINT-2 Hole number of 2nd machining omitting hole

D OMITTING POINT-3 Hole number of 3rd machining omitting hole

E OMITTING POINT-4 Hole number of 4th machining omitting hole

NOTE

It is not necessary to enter all of the OMITTING

HOLE data item.

Circle - Hole pattern : G1215

Data item Comment

B REFERENCE POSITION Z-coordinate of the workpiece surface

L DEPTH Hole depth (usually negative value)

H CENTER POINT (X-AXIS) Center point X-coordinate of the circle

V CENTER POINT (Y-AXIS) Center point Y-coordinate of the circle

R RADIUS Radius of the circle

A START ANGLE Center angle of the 1st hole point

C NUMBER OF HOLE Number of holes along to the circle

D OMITTING POINT-1 Hole number of 1st machining omitting hole

E OMITTING POINT-2 Hole number of 2nd machining omitting hole

F OMITTING POINT-3 Hole number of 3rd machining omitting hole

I OMITTING POINT-4 Hole number of 4th machining omitting hole

NOTE

It is not necessary to enter all of the OMITTING

HOLE data item.
