1.MANUAL GUIDE 0i MANUAL GUIDE 0i B-63864EN/03

- 710 -

1.5.2.3 Chamfering

Data item Comment

CAMFER C Chamfering amount, but plus value only

FEEDRATE Feedrate

NOTE

The feedrate data item is displayed when parameter

No.9341#3(FCD) is set to 1.

[OK] : Fix chamfering figure data and store into memory.

[CANCEL] : Cancel chamfering figure data entering and return to

the contour program list screen.

1.5.2.4 Select Crossing Point of Figure

During the calculation of a contour figure, such as between a line and

an arc for example, there may be cases in which two or more cross

points or figures are possible. In this case, the screen for selecting a

cross point or figure appears.

[PREV.]/[NEXT] : Cross point or figure should be selected is

changed. The active one blinks among some

figures should be selected.

[OK] : Select an active figure, blinking, finally.

[CANCEL] : Cancel a selecting operation. And then, store the

actual figure into memory still keeping it in

pending.
