1.MANUAL GUIDE 0i MANUAL GUIDE 0i B-63864EN/03

- 684 -

1.4.2 Data for Each Canned Cycle

1.4.2.1 Machining type block of Hole machining

Center drilling : G1000

Data item Comment

W MACHINING TYPE 1 : Drilling without dwell

2 : Drilling with dwell

C CLEARANCE Distance from the surface of workpiece to the start

point of actual cutting motion

I REFERENCE POSITION

RETURN

1 : Return to initial point at moving to the next hole

position

2 : Return to R point (start point of actual cutting

motion) at moving to the next hole position

F FEEDARATE Cutting feedrate

P DWELL TIME Dwell time at the bottom of hole, in unit of msec.

Drilling : G1001

Data item Comment

W MACHINING TYPE 1 : Drilling without dwell

2 : Drilling with dwell

3 : Peck drilling

4 : High speed peck drilling

C CLEARANCE Distance from the surface of workpiece to the start

point of actual cutting motion

I REFERENCE POSITION

RETURN

1 : Return to initial point at moving to the next hole

position

2 : Return to R point (start point of actual cutting

motion) at moving to the next hole position

Q CUTTING DEPTH Cutting in depth of one cutting motion

F FEEDARATE Cutting feedrate

P DWELL TIME Dwell time at the bottom of hole, in unit of msec.

Tapping : G1002

Data item Comment

W MACHINING TYPE 1 : Normal tapping

2 : Reverse tapping

3 : Rigid tapping

4 : Reverse rigid tapping

C CLEARANCE Distance from the surface of workpiece to the start

point of actual cutting motion

I REFERENCE POSITION

RETURN

1 : Return to initial point at moving to the next hole

position

2 : Return to R point (start point of actual cutting

motion) at moving to the next hole position

F FEEDARATE Cutting feedrate

P DWELL TIME Dwell time at the bottom of hole, in unit of msec.

L THREADING LEAD Lead of a tapping thread

S SPINDLE SPEED Spindle rotating speed (min-1)
