1.MANUAL GUIDE 0i MANUAL GUIDE 0i B-63864EN/03

- 696 -

1.4.2.7 Machining type block of Groove machining

Grooving - Rough : G1050

Data item Comment

T BOTTOM THICKNESS Removal amount of groove part, distance from the

bottom of groove

J CUT DEPTH OF TOOL –AXIS Cutting depth of one cutting along the tool axis

direction (Z-axis)

H BOTTOM FINISH AMOUNT Finishing amount of the bottom part

K SIDE FINISH AMOUNT Finishing amount of the side wall part

F FEEDARATE OF TOOL-

RADIUS

Cutting feedrate along the tool radius direction

E FEEDARATE OF TOOL-AXIS Cutting feedrate along the tool axis (Z) direction

D TOOL DIAMETER Tool diameter

L CUT AMOUNT OF TOOL-

RADIUS

Cutting amount of the tool radius direction

C CLEARANCE OF TOOL-AXIS Distance from the surface of workpiece to the

approaching point along Z-axis

W UP CUT/DOWN CUT 1 : Carry out down cutting way

2 : Carry out up cut way

Grooving - Bottom finish : G1051

Data item Comment

T BOTTOM THICKNESS Removal amount at bottom part

K SIDE FINISH AMOUNT Finishing amount of the side wall part

F FEEDARATE OF TOOL-

RADIUS

Cutting feedrate along the tool radius direction

E FEEDARATE OF TOOL-AXIS Cutting feedrate along the tool axis (Z) direction

D TOOL DIAMETER Tool diameter

L CUT AMOUNT OF TOOL-

RADIUS

Cutting amount of the tool radius direction

C CLEARANCE OF TOOL-AXIS Distance from the surface of workpiece to the

approaching point along Z-axis

W UP CUT/DOWN CUT 1 : Carry out down cutting way

2 : Carry out up cut way

Grooving - Side finish : G1052

Data item Comment

T BOTTOM THICKNESS Removal amount at bottom part

F FEEDARATE OF TOOL-

RADIUS

Cutting feedrate along the tool radius direction

E FEEDARATE OF TOOL-AXIS Cutting feedrate along the tool axis (Z) direction

D TOOL DIAMETER Tool diameter

S CUTTER COMPENSATION

NO.

Offset number of cutter-R compensation

C CLEARANCE OF TOOL-AXIS Distance from the surface of workpiece to the

approaching point along Z-axis

W UP CUT/DOWN CUT 1 : Carry out down cutting way

2 : Carry out up cut way

R APPROACH/ESCAPE RADIUS Arc radius of approaching and escaping motion
