2.3.22 Screen Set Control

Screen Set control is a control to do various setting of the screen.

This control is a control to set necessary information at MEM make.

This control is not displayed on the CNC screen.

Only a single instance of this control can be placed in a form. More than

one instance cannot be placed.

Signal of notice screen display

It is a function to notify base screen or sub screen to be displayed.

When the screen is displayed, the set signal is turned on.

There is a similar property in Screen Structure Definition control.

When the signal is set in both Screen Structure Definition control

and Screen Set control, setting Screen Structure Definition control

is used.

Enable signal of each action control

This signal is used by the “FP function of indirect specification”.

Please notify the FP function to have completed setting the

argument for the FP function of indirect specification by this

signal.

In the FP function, execution begins when this signal is turned on.

Focus rule tab

This tab is used to enable or disable the common focus movement

rules and the continuous input function for the input support

controls placed on the entire screen.
