FANUC PICTURE for Windows Operators manual Page 269

Operators manual

Page of 308

/ 308

B-66244EN/03 3.FP FUNCTIONS

- 259 -

When 123 is written in the second axis of setting data

number 5421(4 byte type data) on 2path side, and processing

result is written in D200.

idwrset[109_10]

D10 in PMC area is used for indirect data.

D10,11(number) = 5421

D12(axis) = 2

D13(length) = 8

D14,15,16,17(data) = 123 (0 is specified at the

ten keys input.)

D18(pmc) = 9

D19,20(address) = 200

D21(path) = 2 (1 is specified for 1path

side)

idwrset[200_100]

#100 in custom macro variable is used for indirect data.

#100(number) = 5421

#101(axis) = 2

#102(length) = 8

#103(data) = 123 (0 is specified at the ten

keys input.)

#104(pmc) = 9

#105(address) = 200

#106(path) = 2 (1 is specified for 1path

side)

idwrset[300_10000]

#10000 in P code variable is used for indirect data.

#10000(number) = 5421

#10001(axis) = 2

#10002(length) = 8

#10003(data) = 123 (0 is specified at the ten

keys input.)

#10004(pmc) = 9

#10005(address) = 200

#10006(path) = 2 (1 is specified for 1path

side)

1.61 Reading a P code variable(indirect specification)

[Function name]

idrdpmac2

[Data type]

7: Double(Decimal point)

[Format/with arguments]

idrdpmac2[kind_datanum]

[Arguments]

kind Kind and data division of indirect specification

datanum Number of beginning of storage of argument of

indirect specification

[Argument of indirect specification destinations]

number_pmc_address_path

number P code variable number
