B-66244EN/03 APPENDIX A.ERROR MESSAGES

- 289 -

ERROR MESSAGES

This appendix explains error messages.

l Error messages displayed while an application is running under

CNC

•

••

• Cannot open screen for the above reason

For the reason indicated, a screen change failed.

•

••

• CRT file error !!

A screen data file contains invalid data. Recreate the definition

data file and screen data file by using FANUC PICTURE.

•

••

• Function name is illegal !!

In the function action definition for a special key or soft key, an

invalid function name is set. The functions that can be set are the

four FANUC PICTURE cursor movement functions (fp_crlmv,

fp_crrmv, fp_crumv, and fp_crdmv).

•

••

• Impossible to open CRT file !!

A screen data file could not be opened. Check whether the

screen data file set with the basic screen name in the entire

screen definition is present.

•

••

• Impossible to open file: XXXX

The XXXX definition data file could not be opened. Check

whether the definition data file with the screen name set in the

screen action definition for a special key or soft key, or the

definition data file with the screen name set in FPINTENV.DAT

(environment setting file), is present.

•

••

• Impossible to open FP_PAT.DAT file !!

The pattern data file (FP_PAT.DAT) could not be opened.

Check the settings in the CEXEC.D2M command file to see

whether the pattern data file (FP_PAT.DAT) was included

during the creation of a memory card file using dat2mem.com.

•

••

• Insufficient memory

Memory could not be acquired. Enlarge the available memory

area. Alternatively, simplify the created screen to reduce the

amount of screen data.
