B-66244EN/03 APPENDIX B.CNC SCREEN NUMBERS LIST

- 293 -

CNC screen

number

Screen FS16i/18i/21i-M FS16i/18i/21i-T Power Mate i

0x0004 ALARM O O O

0x0104 EXTERNAL MESSAGE O O O

0x0204 ALARM HISTORY O O O

0x0304 MAP MESSAGE O O X

0x0404 OPERATOR'S MESSAGE O O X

0x0504 REMOTE DIAGNOSTICS O O X

0x0604 EXTERNAL/OPERATOR'S MESSAGE

HISTORY

O O X

0x0704 NETWORK MESSAGE O O X

0x0804 DATA SERVER MESSAGE O O X

0x0904 ONLINE CUSTOM SCREEN O O X

0x0a04 C Executor O O O

<USER>(SMALL KEY)

CNC screen

number

Screen FS16i/18i/21i-M FS16i/18i/21i-T Power Mate i

0x0005 PASCAL O O X

0x0105 AUX O O O

0x0205 MACRO O O O

0x0305 MENU O O O

0x0405 GRAPHIC O O X

0x0505 SOLID GRAPHIC O X X

<GRAPHIC>(FULL KEY)

CNC screen

number

Screen FS16i/18i/21i-M FS16i/18i/21i-T Power Mate i

0x0005 GRAPHIC O O X

<CUSTOM>(FULL KEY)

CNC screen

number

Screen FS16i/18i/21i-M FS16i/18i/21i-T Power Mate i

0x0006 PASCAL O O X

0x0106 AUX O O X

0x0206 MACRO O O X

0x0306 MENU O O X

<FAPT>

CNC screen

number

Screen FS16i/18i/21i-M FS16i/18i/21i-T Power Mate i

0x0007 FAPT O O X
