FANUC PICTURE for Windows Operators manual Page 260

Operators manual

Page of 308

/ 308

3.FP FUNCTIONS B-66244EN/03

- 250 -

[Format]

GetDrvVersion[]

[Arguments]

----------

[Description]

The version of the FP driver which operates on CNC is read.

1.53 Reading tool offset amount (indirect specification)

[Function name]

idrdtofs2

[Data type]

4 : 4 bytes(signed)

[Format/with arguments]

idrdtofs2[kind_datanum]

[Arguments]

kind Kind and data division of indirect specification

datanum Number of beginning of storage of argument of

indirect specification

[Argument of indirect specification destinations]

number_type_pmc_address_path

number Offset number

type Offset type

pmc Kind of PMC address for processing result

notification

address PMC address where processing result is

written (The area in two bytes is used from

the specified address)

path Path number

Row of argument when PMC area is specified

Offset from head PMC address (byte)

+0-1 +2 +3 +4-5 +6

Set argument number type pmc address path

[Example]

When the value of the 10th offset number of Tool length

compensation/wear compensation value on 2path side is

read, and processing result is written in D200.

idrdtofs2[109_10]

D10 in PMC area is used for indirect data.

D10,11(number) = 10

D12(type) = 2

D13(pmc) = 9

D14,15(address) = 200

D16(path) = 2 (1 is specified for 1path

side)

idrdtofs2[200_100]

#100 in custom macro variable is used for indirect data.

#100(number) = 10

#101(type) = 2

#102(pmc) = 9

#103(address) = 200
