FANUC PICTURE for Windows Operators manual Page 261

Operators manual

Page of 308

/ 308

B-66244EN/03 3.FP FUNCTIONS

- 251 -

#104(path) = 2 (1 is specified for 1path

side)

idrdtofs2[300_10000]

#10000 in P code variable is used for indirect data.

#10000(number) = 10

#10001(type) = 2

#10002(pmc) = 9

#10003(address) = 200

#10004(path) = 2 (1 is specified for 1path

side)

1.54 Writing tool offset amount (indirect specification)

[Function name]

idwrtofs

[Data type]

4 : 4 bytes(signed)

[Format/with arguments]

idwrtofs[kind_datanum]

[Arguments]

kind Kind and data division of indirect specification

datanum Number of beginning of storage of argument of

indirect specification

[Argument of indirect specification destinations]

number_type_data_pmc_address_path

number Offset number

type Offset type

data Output data(signed 4 bytes)

pmc Kind of PMC address for processing result

notification

address PMC address where processing result is written

(The area in two bytes is used from the specified

address)

path Path number

Row of argument when PMC area is specified

Offset from head PMC address (byte)

+0-1 +2 +3-6 +7 +8-9 +10

Set argument number type data pmc address path

[Example]

When 20 is written in the 10th offset numbers of Tool length

compensation/wear compensation value on 2path side, and

processing result is written in D200.

idwrtofs[109_10]

D10 in PMC area is used for indirect data.

D10,11(number) = 10

D12(type) = 2

D13,14,15,16(data) = 20 (0 is specified at the ten

keys input.)

D17(pmc) = 9

D18,19(address) = 200
