3.FP FUNCTIONS B-66244EN/03

- 224 -

4: 4 bytes (signed)

[Format/with arguments]

absolute[axis]

[Arguments]

axis Axis number

(= from 1 to the maximum number of controlled axes)

[Return value]

Absolute position for the specified axis number

1.8 Reading the machine position of a controlled axis

[Function name]

machine

[Data type]

4: 4 bytes (signed)

[Format/with arguments]

machine[axis]

[Arguments]

axis Axis number

(= from 1 to the maximum number of controlled axes)

[Return value]

Machine position for the specified axis number

1.9 Reading the relative position of a controlled axis

[Function name]

relative

[Data type]

4: 4 bytes (signed)

[Format/with arguments]

relative[axis]

[Arguments]

axis Axis number

(= from 1 to the maximum number of controlled axes)

[Return value]

Relative position for the specified axis number

1.10 Reading the remaining amount of travel along a controlled axis

[Function name]

distance

[Data type]

4: 4 bytes (signed)

[Format/with arguments]

distance[axis]

[Arguments]

axis Axis number

(= from 1 to the maximum number of controlled axes)

[Return value]

Remaining amount of travel for the specified axis number
