FANUC PICTURE for Windows Operators manual Page 74

Operators manual

Page of 308

/ 308

2.FANUC PICTURE (Windows) B-66244EN/03

- 64 -

(Focus movement specification example 3):

There are three groups for 1 to 9, 2 to 15, and 3 to 21. Continuous

input is disabled at the end (9, 15, or 21) of each group. (No

continuous input is performed over a group.) The ← cursor key

causes the focus to move in the direction opposite to that shown

below.

1→4→5→6→7→8→9→ disable

2→10→11→12→13→14→15→ disable

3→16→17→18→19→20→21→ disable

Pressing the ↓or ↑ key causes the focus to move as shown below:

1↔2↔3↔4↔7↔10↔13↔16↔19↔ …↔18↔21↔(1)

Setting:

Each control is assigned with a focusing index number or

TabIndex number in the indicated order. The other controls and

properties are set up as listed in the following tables.

Example of specifying properties on the Focus rule tab of the Screen Set control

Common focus movement rule Direction(for Continuous input)

→ key ↓ key

Continuous input

→ ↓ ← ↑

1 3 þ ¤ ¡ ¡ ¡

Example of setting up properties on the Focus tab for controls with input

Focus movement rule Don’t move focus to the next

control after data input operation.

Focus index or TabIndex

number

↑ ← → ↓

1 0 21 4 2 o

2 1 9 10 3 o

3 2 15 16 4 o

4 3 1 0 0 o

(5-8) 0 0 0 0 o

9 0 0 2 0 þ

10 0 2 0 0 o

(11-14) 0 0 0 0 o

15 0 0 3 0 þ

16 0 3 0 0 o

(17-20) 0 0 0 0 o

21 0 0 1 0 þ

1456

789

2 101112

13 14 15

3 161718

19 20 21
