FANUC PICTURE for Windows Operators manual Page 259

Operators manual

Page of 308

/ 308

B-66244EN/03 3.FP FUNCTIONS

- 249 -

STRT Cycle start state

kind = 2 : Status of axis motion and dwelling

Display Meaning

*** Not in motion or dwelling

MTN Any axis in motion

DWL In dwelling

kind = 3 : Status of M,S,T,B functions

Display Meaning

*** Not in waiting FIN signal

FIN In executing auxiliary functions (waiting

FIN signal)

kind = 4 : Status of emergency stop and reset

Display Meaning

blank Not emergency stop or resetting

--EMG-- Emergency stop

-RESET- Resetting

kind = 5 : Status of alarm

Display Meaning

*** No alarms or warnings

ALM Alarm

BAT Battery low

[Example]

rdncstats[1]

Status information in the state of the automatic operative

method is read.

1.51 Reading amount of D-RAM memory use

[Function name]

rdmemsize

[Data type]

4 : 4 bytes (signed)

[Format/with arguments]

rdmemsize[kind]

[Arguments]

kind 0 : Occupied D-RAM size (byte)

1 : Empty size (byte)

[Description]

Information on the D-RAM status is read.

1.52 Reading FP driver version

[Function name]

GetDrvVersion

[Data type]

6 : String
