B-66244EN/03 3.FP FUNCTIONS

- 265 -

[Format/with arguments]

rdpmcb[adrtype_snumber_bitpos]

[Arguments]

adrtype PMC address type

0: G

1: F

2: Y

3: X

4: A

5: R

6: T

7: K

8: C

9: D

12: E(PMC-SB7)

snumber PMC address where data is read

bitpos Bit position (0 to 7)

[Description]

1 bit of the specified PMC area is read.

[Example]

rdpmcb[9_100_0] The data of bit 1 of D100 is read.

2.5 PMC read (bit) (indirect specification)

[Function name]

idrdpmcb

[Data type]

1: 1 bytes

[Format/with arguments]

idrdpmcb[kind_datanum]

[Arguments]

kind Kind and data division of indirect specification

datanum Number of beginning of storage of argument of

indirect specification

[Argument of indirect specification destinations]

adrtype_snumber_bitpos

adrtype Kind of PMC address

snumber read PMC address

bitpos Bit position

Row of argument when PMC area is specified

Offset from head PMC address (byte)

+0 +1-2 +3

Set argument adrtype snumber bitpos

[Example]

When you read the data of bit 7 of D100 of PMC area.

idrdpmcb[109_10]

D10 in PMC area is used for indirect data.

D10(adrtype) = 9

D11,12(snumber) = 100

D13(bitpos) = 7
