Servo Motor Alpha Series Maintenance manual Page 105

Maintenance manual
4. CONFIRMATION OF
B-65165E/02 START-UP PROCEDURE THE OPERATION
- 75 -
4.3.6.6 Address descriptions and initial values (SPMC)
[Output to the indicator]
Address Description Initial value
d-01 Specifies a data number. 0
d-02 Shift at data output (0 to 31 bits) 0
d-03 Data shift direction
0 : Data is shifted right.
1 : Data is shifted left.
0
d-04 Display format
0 : Decimal notation
1 : Hexadecimal notation(0 to F)
0
[Output to the channel 1]
Initial value
Address Description
A20B-2001-0830 (CH1)
d-05 Specifies a data number 54 (Spindle load level)
d-06 Shift at data output (0 to 31 bits) 6
d-07 Data shift direction
0: Data is shifted right
1: Data is shifted left
0
d-08 Offset
0: Not provided
1: Provided
0
[Output to the channel 2]
Initial value
Address Description
A20B-2001-0830 (CH1)
d-09 Specifies a data number 34 (U-phase current)
d-10 Shift at data output (0 to 31 bits) 8
d-11 Data shift direction
0: Data is shifted right
1: Data is shifted left
0
d-12 Offset
0: Not provided
1: Provided
1
