Servo Motor Alpha Series Maintenance manual Page 43

Maintenance manual
B-65165E/02 START-UP PROCEDURE 2. CONFIGURATIONS
- 13 -
2.2.2.2 400-V input series
(1) Single-axis servo amplifier modules (interface: Type A/B)
Model
Order
specification
Wiring board
specification
Printed circuit
board
specification
Remarks
SVM1-20HV A06B-6085-H102 A16B-2202-0800
SVM1-40HV A06B-6085-H103 A16B-2202-0801
SVM1-60HV A06B-6085-H104 A16B-2202-0802
A20B-2001-0932
(2) Two-axis servo amplifier modules (interface: Type A/B)
Model
Order
specification
Wiring board
specification
Printed circuit
board
specification
Remarks
SVM2-20/20HV A06B-6085-H201 A16B-2203-0210
SVM2-20/40HV A06B-6085-H202 A16B-2203-0211
SVM2-20/60HV A06B-6085-H203 A16B-2203-0212
SVM2-40/40HV A06B-6085-H204 A16B-2203-0213
SVM2-40/60HV A06B-6085-H205 A16B-2203-0214
SVM2-60/60HV A06B-6085-H206 A16B-2203-0215
A20B-2001-0933
(3) Single-axis servo amplifier modules (interface: FSSB)
Model
Order
specification
Wiring board
specification
Printed circuit
board
specification
Remarks
SVM1-20HV A06B-6097-H102 A16B-2202-0800
SVM1-40HV A06B-6097-H103 A16B-2202-0801
SVM1-60HV A06B-6097-H104 A16B-2202-0802
Enclosed in parentheses is the
drawing number of the old
specification.
SVM1-80HV A06B-6097-H105 A16B-2202-0803
A20B-2100-0542
(A20B-2100-0252)
SVM1-320HV A06B-6097-H107 A20B-1007-0592 A16B-2203-0301
(4) Two-axis servo amplifier modules (interface: FSSB)
Model
Order
specification
Wiring board
specification
Printed circuit
board
specification
Remarks
SVM2-20/20HV A06B-6097-H201 A16B-2203-0210
SVM2-20/40HV A06B-6097-H202 A16B-2203-0211
SVM2-20/60HV A06B-6097-H203 A16B-2203-0212
SVM2-40/40HV A06B-6097-H204 A16B-2203-0213
Enclosed in parentheses is the
drawing number of the old
specification.
SVM2-40/60HV A06B-6097-H205 A16B-2203-0214
SVM2-60/60HV A06B-6097-H206 A16B-2203-0215
A20B-2100-0543
(A20B-2100-0253)
