2. CONFIGURATIONS START-UP PROCEDURE B-65165E/02
- 8 -
(2) Power supply modules (PSMR) (200 VAC input, resistance
discharge type), CE-marked products
Model Order specification Unit specification
Wiring board
specification
Printed circuit board
specification
PSMR-3
A06B-6081-H103
(Revision C or later)
A06B-6081-C103
A16B-2202-0542
(Revision 06B or later)
A16B-2001-0890
PSMR-5.5
A06B-6081-H106
(Revision C or later)
A06B-6081-C106
A16B-2202-0541
(Revision 06B or later)
A16B-2001-0890
(3) Power supply modules (PSM) (200 VAC input, power
regeneration type), CE-marked products
Model
Order
specification
Unit
specification
Wiring board
specification
Printed circuit
board
specification
Driver board
specification
Connector
board
specification
A16B-2202-0460
PSM-5.5
A06B-6077-H106
(Revision A)
A06B-6077-C106
(Revision A)
A16B-2202-0461
PSM-11
A06B-6077-H111
(Revision A)
A06B-6077-C111
(Revision A)
A16B-2202-0461
A16B-2202-0420
(Revision 04C or
earlier)
A06B-6077-H115 A06B-6071-C112 A20B-1005-0591 A16B-2202-0080
A20B-2001-
0011
A20B-2001-
0130
PSM-15
A06B-6087-H115
(Revision A)
A06B-6087-C115
(Revision A)
A20B-1006-0160
A16B-2202-0421
(Revision 04C or
earlier)
A20B-2902-
0280
A06B-6077-H126 A06B-6071-C122 A20B-1005-0590 A16B-2202-0080
A20B-2001-
0011
A20B-2001-
0130
PSM-26
A06B-6087-H126
(Revision B or
earlier)
A06B-6087-C126
(Revision B or
earlier)
A20B-1006-0161
A16B-2202-0421
(Revision 04C or
earlier)
A20B-2902-
0280
A06B-6077-H130 A06B-6071-C126 A20B-1005-0592 A16B-2202-0080
A20B-2001-
0011
A20B-2001-
0130
PSM-30
A06B-6087-H130
(Revision B or
earlier)
A06B-6087-C130
(Revision B or
earlier)
A20B-1006-0162
A16B-2202-0421
(Revision 04C or
earlier)
A20B-2902-
0280
(4) Power supply modules (PSMR) (200 VAC input, resistance
discharge type), CE-marked products
Model Order specification Unit specification
Wiring board
specification
Printed circuit board
specification
PSMR-3
A06B-6081-H103
(Revision B or earlier)
A06B-6081-C103
(Revision B or earlier)
A16B-2202-0542
(Revision 05A or earlier)
A16B-2300-0100
PSMR-5.5
A06B-6081-H106
(Revision B or earlier)
A06B-6081-C106
(Revision B or earlier)
A16B-2202-0541
(Revision 05A or earlier)
A16B-2300-0100
