Servo Motor Alpha Series Maintenance manual Page 174

Maintenance manual
3. TROUBLESHOOTING
AND ACTION TROUBLESHOOTING B-65165E/02
- 146 -
3.4.1.3 Alarm code 02
The actual motor speed is largely deviated from the commanded speed.
(1) If this alarm is issued during motor acceleration
(a) The parameter setting of acceleration/deceleration time is
incorrect.
In the following parameter, set the value equivalent to the
spindle inertia plus some margin:
FS0 FS15i FS16i/16, PM-D/F Description
6582 3082 4082 Setting of acceleration/deceleration
time
(b) The parameter for the speed detector is not set correctly.
Referring to "FANUC AC SPINDLE MOTOR α series
Parameter Manual (B-65160E)," set a correct value.
(2) If this alarm is issued during cutting
(a) The cutting load has exceeded the motor output power.
Check the load meter indication, and review the use
condition.
(b) The parameters for output restriction are not set correctly.
Check that the settings of the following parameters satisfy
the machine and motor specifications:
FS0 FS15i FS16i/16, PM-D/F Description
6528 3028 4028 Output restriction pattern setting
6529 3029 4029 Output restriction value
(c) The parameters specific to the motor are not correctly.
Refer to "FANUC AC SPINDLE MOTOR α series
Parameter Manual (B-65160E)."
