Servo Motor Alpha Series Maintenance manual Page 112

Maintenance manual
4. CONFIRMATION OF
THE OPERATION START-UP PROCEDURE B-65165E/02
- 82 -
(3) Internal data conversion (A20B-2001-0830)
Data
No.
Signal
name
Description (All are voltage values on check pins when
the shift amount is 8.)
218 IU Phase U current The current is positive when it is input to the
amplifier.
219 IV Phase V current Model Conversion result
SPM-2.2, 5.5
SPM-11HV
16.7 A/1 V
SPM-11, 15HV 33.3 A/1 V
SPM-15, 25HV 50.0 A/1 V
SPM-22, 45HV 66.7 A/1 V
SPM-26 100 A/1 V
SPM-30, 75HV 133 A/1 V
SPM-45 200 A/1 V
SPM-55 233 A/1 V
162 VDC DC link voltage signal 100 V/1 V (200 V/1 V for SPM-HV)
121 MSA1 Magnetic sensor output MSA signal 1 1.54 V/1 V
(Adjustment value on check board: Single amplitude 2.0 V
min, offset ±300 mV max)
125 MSA2 Magnetic sensor output MSA signal 2 1.54 V/1 V
(4) Spindle control signals (PMC signals)
Data
No.
Description
6
Spindle control signal 1 (command signal from the PMC to spindle)
BIT15 BIT14 BIT13 BIT12 BIT11 BIT10 BIT09 BIT08
RCH RSL INTG SOCN MCFN SPSL *ESP ARST
BIT07 BIT06 BIT05 BIT04 BIT03 BIT02 BIT01 BIT00
MRDY ORCM SFR SRV CTH1 CTH2 TLMH TLML
66
Spindle control signal 2 (control signal from the PMC to spindle)
BIT15 BIT14 BIT13 BIT12 BIT11 BIT10 BIT09 BIT08
*DOPN DSCN SORSL MPOF SLV MORCM
BIT07 BIT06 BIT05 BIT04 BIT03 BIT02 BIT01 BIT00
RCHHG MFNHG INCMD OVR DEFMD NRRO ROTA INDX
12
Spindle status signal 1 (status signal from the spindle to PMC)
BIT15 BIT14 BIT13 BIT12 BIT11 BIT10 BIT09 BIT08
MOAR2 MOAR1 POAR2 SLVS RCFN RCHP CFIN CHP
BIT07 BIT06 BIT05 BIT04 BIT03 BIT02 BIT01 BIT00
ORAR TLM LDT2 LDT1 SAR SDT SST ALM
182
Spindle status signal 2 (status signal from the spindle to PMC)
BIT15 BIT14 BIT13 BIT12 BIT11 BIT10 BIT09 BIT08
BIT07 BIT06 BIT05 BIT04 BIT03 BIT02 BIT01 BIT00
EXOF SOREN MSOVR INCST PC1DT
