Servo Motor Alpha Series Maintenance manual Page 89

Maintenance manual

Page of 284

/ 284

4. CONFIRMATION OF

B-65165E/02 START-UP PROCEDURE THE OPERATION

- 59 -

(2) SPM type 3

SPM input

connector

Connector pin

signal

Check

terminal name

Main sensors Remarks

Phase A: pin 5, 6

Phase B: pin 7, 8

PA1

PB1

M, MZ, and BZ sensors Main sideJY2

Phase Z: pin 1, 2 PS1 MZ and BZ sensors (one-rotation signal) Main side

Phase A: pin 5, 6

Phase B: pin 7, 8

PA2

PB2

M, MZ, and BZ sensors Sub sideJY6

Phase Z: pin 1, 2 PS2 MZ and BZ sensors (one-rotation signal) Sub side

Phase A: pin 5, 6

Phase B: pin 7, 8

and

Phase A: pin 5, 6

Phase B: pin 7, 8

PAD

PBD

α position coder (1024 p) When the main side

is selected by

spindle switching

control, signals are

output on JY4.

When the sub side

is selected, signals

are output on JY8.

Parameters must be

set correctly.

JY4 or

JY8

Phase Z: pin 1, 2

and

Phase Z: pin 1, 2

PSD α position coder (one-rotation signal) When the main side

is selected by

spindle switching

control, signals are

output on JY4.

When the sub side

is selected, signals

are output on JY8.

Parameters must be

set correctly.

pin 18 EXTSC1 Proximity switch (external one-rotation signal) Main side

pin 1, 3 LSA1 Magnetic sensor (LSA signal) Main side

JY3

pin 5, 14 MSA1 Magnetic sensor (MSA signal) Main side(*1)

For A20B-1005-

0740 only

pin 18 EXTSC2 Proximity switch (external one-rotation signal) Sub side

pin 1, 3 LSA2 Magnetic sensor (LSA signal) Sub side

JY7

pin 5, 14 MSA2 Magnetic sensor (MSA signal) Sub side(*1)

For A20B-1005-

0740 only

*1 With A20B-2001-0830, MSA is observed on CH1 or CH2.
