2. CONFIGURATIONS START-UP PROCEDURE B-65165E/02

- 10 -

2.2.2 Servo Amplifier Modules

2.2.2.1 200-V input series

(1) Single-axis servo amplifier modules (interface: Type A/B)

Model

Order

specification

Wiring board

specification

Printed circuit

board

specification

Remarks

SVM1-2 A06B-6079-H121 A16B-2202-0742

SVM1-4 A06B-6079-H122 A16B-2202-0743

SVM1-12 A06B-6079-H101 A16B-2202-0740

SVM1-20 A06B-6079-H102 A16B-2202-0741

SVM1-40S A06B-6079-H103

A16B-2203-0450

(A16B-2202-0760)

Enclosed in parentheses are the

drawing numbers of the old

specifications.

SVM1-40L A06B-6079-H104

A16B-2203-0451

(A16B-2202-0761)

SVM1-80 A06B-6079-H105

A16B-2203-0452

(A16B-2202-0762)

A20B-2001-0930

SVM1-130 A06B-6079-H106

A16B-2203-0454

(A16B-2202-0790)

A20B-2001-0932

SVM1-240 A06B-6079-H107 A20B-1006-0485 A16B-2202-0990

SVM1-360 A06B-6079-H108 A20B-1006-0485 A16B-2202-0991

(2) Two-axis servo amplifier modules (interface: Type A/B)

Model

Order

specification

Wiring board

specification

Printed circuit

board

specification

Remarks

SVM2-3/3 A06B-6079-H291 A16B-2202-0753

SVM2-12/12 A06B-6079-H201 A16B-2202-0750

SVM2-12/20 A06B-6079-H202 A16B-2202-0751

SVM2-20/20 A06B-6079-H203 A16B-2202-0752

SVM2-12/40 A06B-6079-H204

A16B-2203-0590

(A16B-2202-0770)

Enclosed in parentheses are the

drawing numbers of the old

specifications.

SVM2-20/40 A06B-6079-H205

A16B-2203-0591

(A16B-2202-0771)

SVM2-40/40 A06B-6079-H206

A16B-2203-0592

(A16B-2202-0772)

A20B-2001-0931

SVM2-40/80 A06B-6079-H207

A16B-2203-0593

(A16B-2202-0773)

SVM2-80/80 A06B-6079-H208

A16B-2203-0594

(A16B-2202-0774)

SVM2-40L/40L A06B-6079-H209

A16B-2203-0595

(A16B-2202-0775)

A20B-2001-0933
