Servo Motor Alpha Series Maintenance manual Page 128

Maintenance manual
2. ALARM NUMBERS AND
BRIEF DESCRIPTIONS TROUBLESHOOTING B-65165E/02
- 100 -
Alarm
No.
SVM SPM PSM Description Remarks
441 Current offset error 3.3.8
442 05 Converter: DC link charging/inverter DB 3.1
443 02 Converter: cooling fan stopped 3.1
444 1 Inverter: internal cooling fan stopped 3.2
445 Soft disconnection alarm 3.3.4
446 Hard disconnection alarm Not
issued
447 Hard disconnection alarm (separate) 3.3.4
448 Feedback mismatch alarm 3.3.8
449 8.
9.
A.
b.
C.
d.
E.
Inverter: IPM alarm (L axis)
(M axis)
(N axis)
(L and M axes)
(M and N axes)
(L and N axes)
(L, M, and N axes)
3.2
453 Soft disconnection alarm (α pulse coder) 3.3.4
Spindle alarm (n represents a spindle number. Example: n = 1 for the
first spindle)
Alarm
No.
SVM SPM PSM Description Remarks
749 A Program ROM error 3.4
749 A0 Program ROM error 3.4
749 A1 Program RAM error 3.4
749 A2 Program RAM error 3.4
749 A3 SPM control circuit clock error 3.4
749 A4 SRAM parity error 3.4
7n01 01 Motor overheat 3.4
7n02 02 Excessive speed deviation 3.4
7n03 03 DC link fuse blown 3.4
7n04 04 06 Input power supply open phase and power
supply failure
3.4
7n07 07 Excessive speed 3.4
7n09 09 Main circuit overload 3.4
7n11 11 07 DC link overvoltage 3.4
7n12 12 DC link overcurrent/IPM alarm 3.4
750 13 CPU internal data memory error 3.4
7n15 15 Output switching/spindle switching alarm 3.4
750 16 RAM error 3.4
750 19 Excessive offset of the phase U current
detection circuit
3.4
750 20 Excessive offset of the phase V current
detection circuit
3.4
