B-65165E/02 START-UP PROCEDURE 2. CONFIGURATIONS

- 17 -

(2) α series spindle amplifier modules (SPM), type 2 (Cs contour

control/BZ sensor (separate built-in sensor) specification)

CE-marked products

Model Order specification Unit specification

Wiring board

specification(*1)

Printed circuit

board

specification

ROM (series)

SPM-2.2 A06B-6078-H302#H500 A06B-6078-H302 A16B-2202-0680

A16B-2202-0433

A20B-2901-0851

SPM-5.5 A06B-6078-H306#H500 A06B-6078-H306 A16B-2202-0681

SPM-11 A06B-6078-H311#H500 A06B-6078-H311 A16B-2202-0682

A16B-2202-0434

A20B-2901-0851

SPM-15 A06B-6088-H315#H500 A06B-6088-H315

A20B-1006-0486

(A20B-1006-0480)

A20B-2902-0390

SPM-22 A06B-6088-H322#H500 A06B-6088-H322

A20B-1006-0487

(A20B-1006-0481)

A20B-2902-0390

SPM-26 A06B-6088-H326#H500 A06B-6088-H326

A20B-1006-0488

(A20B-1006-0482)

A20B-2902-0390

SPM-30 A06B-6088-H330#H500 A06B-6088-H330

A20B-1006-0489

(A20B-1006-0483)

A20B-2902-0390

SPM-45 A06B-6088-H345#H500 A06B-6088-H345

A20B-1007-0591

(A20B-1006-0690)

A20B-2002-0080

A16B-2202-0435

A20B-2901-0851

A06B-6072-H500

(9D00, 9D0A)

Non-CE-marked products

Model Order specification Unit specification

Wiring board

specification

Printed circuit

board

specification

ROM (series)

SPM-2.2 A06B-6078-H302#H500 A06B-6078-H302 A16B-2202-0470

A16B-2202-0433

A20B-2901-0851

SPM-5.5 A06B-6078-H306#H500 A06B-6078-H306 A16B-2202-0471

SPM-11 A06B-6078-H311#H500 A06B-6078-H311 A16B-2202-0472

A16B-2202-0434

A20B-2901-0851

SPM-15 A06B-6088-H315#H500 A06B-6088-H315

A20B-1006-0170

A20B-2902-0280

SPM-22 A06B-6088-H322#H500 A06B-6088-H322

A20B-1006-0171

A20B-2902-0280

SPM-26 A06B-6088-H326#H500 A06B-6088-H326

A20B-1006-0172

A20B-2902-0280

A16B-2202-0435

A20B-2901-0851

A06B-6072-H500

(9D00, 9D0A)

*1 Enclosed in parentheses are the drawing numbers of the old

specifications.
