Servo Motor Alpha Series Maintenance manual Page 86

Maintenance manual
4. CONFIRMATION OF
THE OPERATION START-UP PROCEDURE B-65165E/02
- 56 -
No. Description Action
06 Although no output switching option is
set, low-speed winding is selected
(RCH = 1).
Check the software option for
spindle output switching and the
power line status signal (RCH).
07 Although Cs contour control mode is
specified, neither SFR nor SRV is input.
Check the sequence (CON, SFR,
and SRV).
08 Although servo mode (rigid tapping or
spindle positioning) is specified, neither
SFR nor SRV is input.
Check the sequence (SFR and
SRV).
09 Although spindle synchronization mode
is specified, neither SFR nor SRV is
input.
Check the sequence (SPSYC,
SFR, and SRV).
10 In Cs contour control mode, another
operation mode (servo mode, spindle
synchronization, or orientation) is
specified.
Do not specify another operation
mode during execution of the Cs
contour control command. Before
entering another mode, cancel the
Cs contour control command.
11 In servo mode (rigid tapping or spindle
positioning), another operation mode
(Cs contour control, spindle
synchronization, or orientation) is
specified.
Do not specify another operation
mode during execution of the
servo mode command. Before
entering another mode, cancel
servo mode.
12 During spindle synchronization,
another operation mode (Cs contour
control, servo mode, or orientation) is
specified.
Do not specify another operation
mode during execution of the
spindle synchronization
command. Before entering
another mode, cancel the spindle
synchronization command.
13 When an orientation specification is
specified, another operation mode (Cs
contour control, servo mode, or
synchronization control) is specified.
Do not specify another operation
mode during execution of the
orientation command. Before
entering another mode, cancel the
orientation command.
14 The SFR signal and SRV signal are
input at the same time.
Input one of the SFR and SRV
signals.
15 Although the parameter to use the
differential mode function (FS16i: bit 5
of parameter No. 4000 = 1) is set, Cs
axis contour control is specified.
Check the setting of the
parameter (FS16i: bit 5 of
parameter No. 4000) and the PMC
signal (CON).
16 Although the parameter not to use the
differential mode function (FS16i: bit 5
of parameter No. 4000 = 0) is set, a
differential speed mode command
(DEFMD) is input.
Check the setting of the
parameter (FS16i: bit 5 of
parameter No. 4000) and the PMC
signal (DEFMD).
17 The parameter settings for the speed
detector (FS16i: bits 2, 1, and 0 of
parameter No. 4011) are invalid.
(There is no speed detector that
matches the settings.)
Check the parameter settings
(FS16i: bits 2, 1, and 0 of
parameter No. 4011).
