Servo Motor Alpha Series Maintenance manual Page 42

Maintenance manual
2. CONFIGURATIONS START-UP PROCEDURE B-65165E/02
- 12 -
(6) Two-axis servo amplifier modules (interface: FSSB)
Model
Order
specification
Wiring board
specification
Printed circuit
board
specification
Remarks
SVM2-3/3 A06B-6096-H291 A16B-2202-0753
SVM2-12/12 A06B-6096-H201 A16B-2202-0750
SVM2-12/20 A06B-6096-H202 A16B-2202-0751
SVM2-20/20 A06B-6096-H203 A16B-2202-0752
A20B-2100-0541
(A20B-2100-0251)
When using HRV3, use the following
boards together:
Wiring board: A16B-2202-075X
Printed circuit board:
A20B-2100-054X
SVM2-12/40 A06B-6096-H204
A16B-2203-0590
(A16B-2202-0770)
SVM2-20/40 A06B-6096-H205
A16B-2203-0591
(A16B-2202-0771)
SVM2-40/40 A06B-6096-H206
A16B-2203-0592
(A16B-2202-0772)
A20B-2100-0541
(A20B-2100-0251)
SVM2-40/80 A06B-6096-H207
A16B-2203-0593
(A16B-2202-0773)
SVM2-80/80 A06B-6096-H208
A16B-2203-0594
(A16B-2202-0774)
SVM2-40L/40L A06B-6096-H209
A16B-2203-0595
(A16B-2202-0775)
A20B-2100-0543
(A20B-2100-0253)
When using HRV3, use the following
boards together:
Wiring board: A16B-2203-059X
Printed circuit board:
A20B-2100-054X
(7) Three-axis servo amplifier modules (interface: FSSB)
Model
Order
specification
Wiring board
specification
Printed circuit
board
specification
Remarks
SVM3-12/12/12 A06B-6096-H301 A16B-2202-0780
SVM3-12/12/20 A06B-6096-H302 A16B-2202-0781
SVM3-12/20/20 A06B-6096-H303 A16B-2202-0782
SVM3-20/20/20 A06B-6096-H304 A16B-2202-0783
SVM3-12/12/40 A06B-6096-H305 A16B-2202-0784
SVM3-12/20/40 A06B-6096-H306 A16B-2202-0785
SVM3-20/20/40 A06B-6096-H307 A16B-2202-0786
A20B-2100-0260
