7.2 Parameter List

324

22) For pitch error compensation

03601

Cs contour control axis pitch error

compensation during simple spindle

synchronization

#1 EPC : The pitch error compensation on an axis of Cs

contour control on the slave side during simple

synchronous spindle control is, the same as

that on the master axis(0)/just for the slave

axis(1)

T series

PRM

3661–3674,

3676–3684

03605 Error compensation function setting <Axis>

#0 BPD : Bi–direction pitch error compensation is, not

used(0)/used(1)

(This parameter is valid if PRM3401#0 is set to

0.)

#2 IST : When the interpolated straightness

compensation option is added, the function to

select is, 128–point straightness

compensation(0)/interpolated straightness

compensation(1)

PRM5700

or later,

13381 or

later

03620 Pitch error compensation point number for the

reference position for each axis

<Axis>

Valid data

03621 Pitch error compensation point number of

negative direction for each axis

range :

0 - 1023

03622 Pitch error compensation point number of

positive direction for each axis

03623 Magnification for pitch error compensation for

each axis (0 to 100)

<Axis>

03624 Interval between pitch error compensation

points for each axis [Increment system]

<Axis>

03625 Travel distance per revolution in pitch error

compensation of rotation axis type

[Detection unit]

<Axis>

03626 Number of pitch error compensation point at

the farthest end in the negative direction (for

movement in the negative direction)

<Axis>

03627 Pitch error compensation (absolute value) at

reference position when a movement to the

reference position is made from the direction

opposite to the direction of reference position

return [Detection unit]

<Axis>

PRM

1006#5
