15. WAVEFORM DIAGNOSTIC FUNCTION

809

Pressing the [SATART] soft key starts data sampling. While sampling is

being performed, S0AMPLING blinks at the top of the screen. Once data

sampling has been completed, a waveform is automatically displayed.

WAVE DIAGNOS. (GRAPHIC) O1234 N12345

CH1 CH2

[ START ] [ TIME³ ] [ ²TIME ] [ H–DOBL ] [ H–HALF ]

EDIT **** ******

15.2.2 Drawing a waveform for storage type waveform diagnosis

To use storage type waveform diagnosis, set 100 for the display start

condition. The maximum data width for storage type waveform diagnosis is

32760 ms. Data must be sampled before starting drawing. The next page

explains sampling in detail.

Pressing the [START] soft key loads stored data. While the data is being

loaded, SAMPLING blinks at the top of the screen. Once the data has been

loaded, a waveform is displayed. The date on which the data was stored is

displayed at the top left of the screen. If the [START] soft key is pressed while

data is being stored, storage is stopped and the waveform for the data stored

up to that point is displayed. The WAVE DIAGNOS. (MEMORY) screen

indicates whether data is being stored.

[ START ] [ TIME³ ] [ ²TIME ] [ H–DOBL ] [ H–HALF ]

WAVE DIAGNOS. (GRAPHIC) O1234 N12345

CH1 02/01/13 12:15:00 CH2

EDIT **** *** ***
