11. ETHERNET

729

#6 #5 #4 #3 #2 #1 #0

0810

MONO

TIME BGS

[Data type] Bit

BGS Performs the following when the FACTOLINK screen is

not displayed.

1 : Enables logging in the background.

0 : Disables logging.

TIME Selects the time display format.

1: “01/11/12 00:00” format

0: “Wed Nov 12 00:00:00” format

MONO FACTOLINK screen display color

1 : Monochrome

0: Color

0811

Type of logging

[Data type] Byte

[Valid data range] 0, 1, 10, 20, 21

0 : D address area

1 : R address area

10: Fixed data only

20: D address area + fixed data

21: R address area + fixed data

0812

PMC address for logging data

[Data type] Word

[Valid data range] 0 to 65535

Set a start PMC address for storing logging data.

0813

Data length of logging data

[Data type] Word

[Unit of data] Number of bytes

[Valid data range] 0 to 65535

Set the data length of logging data.

0814

Trigger PMC address for logging

[Data type] Word

[Valid data range] 0 to 65535

Set a PMC address that serves as a trigger for

specifying logging data.

0815

Logging data transmission interval

[Data type] 2–Word

[Unit of data] Seconds

[Valid data range] 0 to 4294967295

Set a time interval used for transmitting logging data

(fixed data only).

If 0 is set, logging data is transmitted at connection time

only.
