The fields of the program list are as follows:
(1) NO : Program number
(2) TYPE : Program type
– CNV : Program created by conversational editing function [1]
– OPT : Program created by optimal process editing function [2]
– CAP : Program created by NC statement output function [4]
– NC : NC statement program created by NC
(3) NAME : Program name. A name of up to 16 alphanumeric characters can be specified.
(4) CREATE DATE : Day and time when the program was created
(5) SIZE : Program size (number of characters). The size is calculated in units of pages (80 char-
acters). The value for size is, therefore, a multiple of 80.
NOTE To select a program from the program list screen, position the cursor to the desired program, then
press the [PROG.SELECT] key.
The soft keys have the following functions:
– [PROG.SELECT]
Pressing this soft key enables editing of the program to which the cursor is positioned. The editing screen
is displayed. If this soft key (or the MDI <INPUT> key) is pressed after a program number has been en-
tered, the program is registered as a new program. Thus, the editing screen for creating a new program
is displayed.
– [PROG.COPY]
Enables copying of the program to which the cursor is positioned. When this soft key is pressed, the pro-
gram copy screen is displayed, as shown below. If this soft key (or the MDI <INPUT> key) is pressed after
a program number has been entered, the corresponding program can be copied.
INPUT NEW PROGRAM NUMBER. >_
CANCELCOPY
EXEC
PROGRAM DIR. PAGE 01/01 EDIT
PROGRAM NO. USED: 13 FREE: 987
MEMORY AREA USED: 4480 FREE: 33120
NO. TYPE NAME CREATE DATA SIZE
0001 CAP TEST–1 DEMO 94–10–06 11:47 80
0002 CAP TEST–2 SUS304 94–10–06 11:49 80
0003 CAP TEST–3 FCD45
0004 CAP TEST–4 SKD11
0005 CAP TEST–5 SUS41
0006 CAP TEST–6 ALUME
0007 CAP TEST–7 SPECIAL
0010 CAP U–AXIS DEMO
0011 OPT U–AXIS DEMO
1000 CAP MANUAL–1
1002 OPT U–AXIS DEMO
1003 CNV MANUAL–1
2000 NC
PROGRAM DIR. : 1
O0001 O0002 O0003 O0004 O0005 O0006
O0007 O1000 O0010 O0011 O1002 O1003
O2000
On the screen, enter a number for the program to hold the copy, then press the [COPY EXEC] soft key. The
selected program is copied. If the program to hold the copy satisfies any of the following conditions, a message
is displayed:
1) If the number specified for the program to hold the copy already exists
→The message INPUT PROGRAM IS ALREADY REGIST. is displayed. To overwrite the existing pro
gram, press the [OVERWRITE] soft key.
2) If the number specified for the program to hold the copy is the same as that of the program to be copied
→The message INPUT PROGRAM NUMBER IS ORIGIN is displayed.
