B–63294EN/02 1. PARAMETERS
– 437 –
FANUC standard settings
9470 Hole cut–in angle assumed during contour pocketing B (deg) 0
Feedrate assumed during movement in the tool diameter direction in
9471 0
contour pocketing B (rapid traverse if 0)
Feedrate assumed during movement in the tool axis direction in
9472 0
contour pocketing B (rapid traverse if 0)
Clearance amount in the tool diameter direction during contour
9473 3000
pocketing B
9474 Clearance amount in the tool axis direction during contour pocketing B 1000
#7 #6 #5 #4 #3 #2 #1 #0
FANUC standard settings
9475 CHK CNR MOV ILA 00000000
ILA : Specify whether to machine the top of islands during contour pocketing B.
0 : Machines the top by controlling the depth of cut.
1 : Does not machine the top.
MOV : During contour pocketing B, the movement during in–feed is performed with:
0 : Surface + parameter No. 9474
1 : Machining surface + parameter No. 9474
CNR : Specify the cutting method at corners during contour pocketing B.
0 : Interpolates corners with arcs.
1 : Interpolates corners with straight lines.
CHK : Specify whether to check pocketing to see if there are uncut portions during contour
pocketing B.
0 : Does not perform the check.
1 : Performs the check.
FANUC standard settings
Argument representing the input item ”CUTTING DRCT.” on the
9476 85
contour pocketing preparation screen
As character codes, set the decimal equivalents of ASCII codes.
Set ”85” to use FANUC standard macros.
FANUC standard settings
Argument representing the input data ”SPIRAL” on the contour
9477 3
pocketing preparation screen
Set ”3” to use FANUC standard macros.
