SUPER CAPi M Operators manual Page 428

Operators manual

Page of 462

/ 462

B–63294EN/02

1. PARAMETERS

– 418 –

1.3 CAP Control

FANUC standard settings

9101 Program number of the input end check macro 9927

9102 Number of the machining menu containing the initial settings 9

Number of the machining menu containing the initial settings specified by the TT instruction. The machining

menu number specified by the TT instruction is used for subsequent operations.

FANUC standard settings

9103 Number of the detailed menu containing the initial settings 1

9104 Number of the machining menu containing the end settings 9

9105 Number of the detailed menu containing the end settings 2

#7 #6 #5 #4 #3 #2 #1 #0 FANUC standard settings

9106 UMC SCL MDL MSJ AWK SGM 01000000

SGM = 0 : FANUC standard macros are used.

= 1 : Macros partially modified are used.

AWK = 0 : In animated simulation, the workpiece coordinate system is disabled.

= 1 : In animated simulation, the workpiece coordinate system is enabled.

MSJ = 0 : Modes are displayed in English, as are messages.

= 1 : Modes are displayed in Japanese, as are messages.

MDL = 0 : Modal calling (G66) can be specified.

= 1 : Modal calling (G66) cannot be specified.

SCL : When control is in the graphic screen

= 0 : Scaling is always turned off.

= 1 : Scaling is turned on only when the specified program number differs from the program

number subject to previous scaling.

UMC = 0 : Tool change macros and end setting macros do not call user programs.

= 1 : Tool change macros and end setting macros call user programs.

#7 #6 #5 #4 #3 #2 #1 #0

FANUC standard settings

9107 AT2 AT1 11100000

Next tool control number embedding

AT1 = 0 : Embedding is not performed when control is returned from menu 1.

= 1 : Embedding is performed when control is returned from menu 1.

AT2 = 0 : Embedding is not performed when control is returned from menu 2.

= 1 : Embedding is performed when control is returned from menu 2.
