2. MACHINING MENU DESCRIPTIONS
– 407 –
Operation
Select “6. PROGRAM EXEC” on the basic menu screen.
(1) Retract the tool and replace it with a new one on the screen of MDI or handle operation.
When you select the MDI mode, the following screen is displayed. Input G or M code from CRT/MDI
panel and then press the cycle start button in order to change the tool.
EXECUTION
BOLT HOL CIR
PROCESS END
MDI STOP ***** *****
DEST
TO GO
MODALNC
FORMAT
NEXT
BLOCK
< ABS
COOD
NO. CYCLE PROCESS TOOL NAME TOOL NO N–DIA FEED SPINDL
001 AUXILIARY INITIAL SETTING
002 FACING FACING PREP. FACE MILL 73
FACING PREP. FACE MILL 71
FACING SQUARE BIDIR
PROCESS END
003 HOLE TAPPING CENTER DRILL 3
TAPPING TAP 25
HOLE PATTERN PARALLELOGRAM
PROCESS END
REL
COOD
ALL
COOD
004 HOLE DRILLING CENTER 73
DRILLING DRILL 71
HOLE PATTERN ARC SAME SP
005 SIDE CUTTING SIDE PREP. END MI 3
SIDE PREP. END MI 15
SIDE CUTTING SQUARE O–SIDE
PROCESS END
M06
S0
T12
B0
D0
H0
PROGRAM (MDI)
PROGRAM O1000 N00001 (TEST PROGRAM) EXE BLOCK: 123
M3
F0
S0
HD.T 0 NX.T 0
D0
H0
B0
(MODAL)
G 90 17 00 ***
X 0.000 Y 0.000 Z 50.000
Using parameter No. 3108, the display of the modal T code can be changed.
#7 #6 #5 #4 #3 #2 #1 #0
3108 PCT
The modal T code is displayed as:
PCT = 0 : T.
= 1 : HD.T and NX.T.
HD.T : Tool on the spindle
NX.T : Tool for the next process
“HD.T” and “NX.T” is specified by PMC with WINDW function
(COMMAND 150H).
(2) When necessary, change the offset amount on Tool Used List screen which you select “8. CAP DATA”
menu. If Listing is necessary, select the EDIT mode and press the softkey [LISTING].
(3) Then, restore the screen of CAP program execution and restore the MEM mode.
(4) Turn on the program restart switch on the machine operator’s panel.
005 SIDE CUTTING SIDE PREP. END MI 3
SIDE PREP. END MI 15
SIDE CUTTING SQUARE O–SIDE
PROCESS END
BOLT HOL CIR
PROCESS END
001 AUXILIARY INITIAL SETTING
002 FACING FACING PREP. FACE MILL 73
FACING PREP. FACE MILL 71
FACING SQUARE BIDIR
PROCESS END
003 HOLE TAPPING CENTER DRILL 3
TAPPING TAP 25
HOLE PATTERN PARALLELOGRAM
PROCESS END
004 HOLE DRILLING CENTER 73
DRILLING DRILL 71
HOLE PATTERN ARC SAME SP
NO. CYCLE PROCESS TOOL NAME TOOL NO N–DIA FEED SPINDL
PROGRAM O1000 N00001 (TEST PROGRAM) EXE BLOCK: 123
RESTART
BLOCK
SET
RE–
START
<
(*4)
MEM ***** ***** *****
(ABS–COOD)
X– 12345. 678
Y 0. 000
Z 0. 000
X: * * * * * 0%
Y: * * * * * 0%
Z: * * * * * 0%
S: * * * * * 0%
LOAD
M3
F0
S0
HD.T 0
D0
H0
F 0 MM/MIN
S0
(5) Press [RESET] on the CRT/MDI panel.
