SUPER CAPi M Operators manual Page 22

Operators manual
B–63294EN/021. OVERVIEW OF Super CAPi M
– 12 –
1.2 Creating a Machining Program [Basic Menu 1]
A machining program is created by the following procedure:
Start
Program creation screen
Automatic
Initial setting
– Enter the initial data (workpiece material, coolant,
reference coordinate system) required for machining.
Selection of a machining menu
– Select a desired machining menu.
Specification of the machining data
– In response to messages displayed on the screen,
(1) Specify a machining method. → Position on the
Z–axis, tool (preparation menu)
(2) Specify the figure data. → Positions on the X– and
Y–axes (figure menu)
(3) Specify the process end.
Repeat these steps until all machining data is speci
fied.
Automatic
Program end
– Select [PROGRM END].
End
> INPUT PROGRAM NO.
4 3 2 1
â
PROG.
SELECT
â
NC
LAN-
GUAGE
POCKET
/GROOV
SIDE
CUTING
FACINGHOLE
PROGRM
END
AUX-
ILIARY
2+1/2
CCV
2+1/2
CVX
PROGRM
END
â
AUX-
ILIARY
2+1/2
CCV
2+1/2
CVX
Title input
– Enter a program name.
