SUPER CAPi M Operators manual Page 325

Operators manual
B–63294EN/02
2. MACHINING MENU DESCRIPTIONS
– 315 –
2. When (B), and (Q) are programmed
⇒ As with 1. above, the contact point selection request screen is displayed. Select a desired
contact point on the screen.
21
Q
3. When (Y) is programmed
⇒ As with 1. above, the contact point selection request screen is displayed. Select a desired
contact point on the screen.
21
YY
4. When (B) and (X) are programmed
⇒ From the two contact points, select the contact point whose X coordinate is equal to (X).
If there is no contact point whose X coordinate is equal to (X), the contact point selection
request screen is displayed.
1
X
