SUPER CAPi M Operators manual Page 361

Operators manual

Page of 462

/ 462

B–63294EN/02

2. MACHINING MENU DESCRIPTIONS

– 351 –

2.12.2.2 Inner contour

INPUT THE Z COORD OF THE UPPER SURFACE OF THE WORKPIECE.

PROCES

WINDOW

F.S.

AUTO

INPUT

END

GUIDAN

TOOL

INFORM

PROGRAM O0010(U–AXIS DEND) PAGE :01/ CREATING

U–AXS MACHIN :INNER CONTOR

NO. CYCLE PROCESS TOOL NAME

001 AUXILIARY INITAL SETING

MAX NUM.OF TOOLS–10

GROUP COPY :YB= UNUSED HOLE DIA. : X= TOOL ID NO. : T=

COORDINATES : W= * FINISHU : U= 0.

WK SURFACE :YA= FINISHZ : Y= 0.

EFFEC DEPTH : V= CUT–SPD CNST:YF= EFFECT

U(R,Z)

GUIDAN

U–AXS MACHIN:INNER

GROUP COPY :YB= UNUSED HOLE DIA. : X= 20. TOOL ID NO. : T= 126.

COORDIANTES : W= * FINISHU : U= 1.

WK SURFACE :YA= 0. FINISHZ : Y= 0.

EFFEC DEPTH : V= 20. CUT–SPD CNST:YF= EFFECT

001 AUXILIARY INI

NO. CYCLE PRO

INPUT THE TOOL ID NUMBER OF THE TOOL TO BE USED.

WINDOW

CHANGE

F.S.

AUTO

INPUT

END

TOOL

INFORM

PROGRAM O0010(U–AXIS DEMO) PAGE :01/ CREATING

CUTTING DATA1/2 PROCESS4 PROCESS3 PROCESS2 PROCESS1

TOOL ID NO. T= 128. 19. 3.

TOOL NAME Q=INN–GENRAL INN–GENRAL DRILL CENT.DRILL

PROCESS B= FINISHING ROUGHING HOLE HOLE

H OFFSET NO. H= 126. 128. 119. 103.

D OFS./DIA. D= 126. 128. 20. 3.

CUT PT. U/R R= * * 3. 3.

CUT PT. Z/Z Z= * * –24. –3.

ESCAPE/DWELL E= 0. 1.111 0. 0.

COOLANT M= COOLNT M7 COOLNT M7 COOLNT M7 COOLNT M7

CUT/SPIN–SPD S= 40. 50. 100. 16.

FEED RATE F= 50. 100. 239. 17.

CUT–DPTH K= * 5. * *

S–DRCT. YD= NORMAL NORMAL * *

126.

1 2 3 4 5 6 7 8

YB GROUP

COPY

UNUSED A–GROUP B–GROUP C–GROUP

W COORDI-

NATES

UNUSED WORK CO

WORK CO

YF CUT–SPD

CNST

EFFECT INEFFECT

B PROCESS ROUGH-

ING

FINISH HOLE MA-

CHINING

M COOLANT COOLANT

COOLANT

NONE

YB DIRECTION

OF ROTA-

TION

FORWARD REVERSE

(1) Screen explanation

This menu is always selected first when inner U–axis machining of an arbitrary figure is to be performed

using the contour function.

Input the Z–direction position data necessary for the contour program and the data related to the tool.

When a tool ID No. (T) is input, the machining process is automatically determined with the previous tool.

There are three machining processes, that is, roughing, finishing, and hole machining.
