For axis-type diagnostic data:

N data number A1 P data A2 P data ;

A : A value that follows A is output as an axis number. This

applies only to axis-type diagnostic data.

A1 = first-axis data; A2 = second-axis data

For diagnostic data

0000 to 09999 20000+(diagnose number)

For PMC address

G0000 to 0255 21000+(G address number)

F0000 to 0255 23000+(F address number)

Y0000 to 0127 25000+(Y address number)

Y1000 to 1063

X0000 to 0127 27000+(X address number)

X1000 to 1063

A0000 to 0024 29000+(A address number)

R0000 to 1499 30000+(R address number)

R9000 to 9117

T0000 to 0079 40000+(T address number)

K0000 to 0019 41000+(K address number)

C0000 to 0079 42000+(C address number)

D0000 to 2999 43000+(D address number)

(NOTE) When diagnostic data is output, character data is not

output directly as ISO/EIA tape codes.

Signals indicating the start number of data items to be output (punched)

EDG0 to EDG15 <G252 to G253>

[Classification] Input signal

[Function] ･When diagnostic data or macro variable data is to be output,

specify a start data number in EDG0 to EDG15 by using a 16-

bit binary code.
