10. MISCELLANEOUS FUNCTIONS

B–63172EN/01

NC FUNCTION

When up to eight digits immediately after address M are specified, a

32–bit binary code is output. The maximum number of input digits can

be specified with a parameter. This binary code is used for on/off control

of the machine. A block can usually contain up to three M codes although

only one of them is effective.

The following M codes are used for special purposes:

M00 : Program stop

M01 : Optional stop

M02 : End of program

M30 : End of program and tape rewind

The above M codes can also be output in binary codes.

M98 (subprogram call), M99 (return from a subprogram), and an M code

(set with a parameter) for calling a subprogram or custom macro are

processed in the CNC, so that no signal is output.

Up to five M codes can be simultaneously specified in one block.

As these M codes are simultaneously sent to PMC side, the machining

cycle time compared with the conventional 1–block single M command

is reduced.

Example)

(i) 1–block single M command

M40;

M50;

M60;

G28G91X0Y0Z0;

(ii)1–block plural M command

M40M50M60;

G28G91X0Y0Z0;

NOTE

1 The maximum input value of the first M code is 99999999,

while the maximum input values of the second and five M

codes are 65535.

2 A strobe signal is provided for each of the first to five M

codes (MF, MF2, MF3, MF4, and MF5).

When all the operations for the first to third M codes are

completed, completion signal FIN is output.

10.1

MISCELLANEOUS

FUNCTIONS

10.2

1–BLOCK PLURAL M

COMMAND
