Power Mate i-Model D/H Descriptions Page 252

Descriptions

Page of 324

/ 324

TITLE

B-63173EN-1/02

EDIT

DATE DESIG. DESCRIPTION

FANUC Power Mate i-D/H

Analog input function

Connection manual (function)

DRAW.NO. CUST.

SHEET

990624 New design

F206

#7 #6 #5 #4 #3 #2 #1 #0

AD05 AD04 AD03 AD02 AD01 AD00 0 0

#7 #6 #5 #4 #3 #2 #1 #0

ADSGN AD12 AD11 AD10 AD09 AD08 AD07 AD06

F207

Please modify items of F206 and F207 in [A.1.1 Power Mate i –MODEL D/H ADDRESS LIST] o

[APPENDIX A Interface between CNC and PMC] as the following.

Function Signal name Symbol Address PMi-D PMi-H Items

Analog input Analog input signal

AD00∼ADSGN F206#2∼F207#7

○○

Please add the following description after [I/O DEVICE EXTERNAL CONTROL FUNCTION] in [A.2.1

SIGNAL LIST (Order of Function)] of [APPENDIX A Interface between CNC and PMC].

Symbol Signal name Address PMi-D PMi-H Items

AAD00∼ADSGN Analog input signal F206#2∼F207#7 ○○

Please add the following description after [ACT] in [A.2.2 SIGNAL LIST (Order of Symbol)] o

[APPENDIX A Interface between CNC and PMC].

Address Signal name Symbol PMi-D PMi-H

Items

F206#2∼F207#7 Analog input signal AD00∼ADSGN ○○

Please add the following description after [F190] in [A.2.3 SIGNAL LIST (Order of Address)] o

[APPENDIX A Interface between CNC and PMC].
