B-64254EN/02 GENERAL 1.OVERVIEW OF THIS MANUAL
- 3 -
1 OVERVIEW OF THIS MANUAL
This manual describes the functions of "TURN MATE i" for the
Series 0i-TC and Series 0i Mate-TC.
For other functions, other than TURN MATE i, refer to the operator’s
manual for the Series 0i-TC or Series 0i Mate-TC.
The specifications and features of TURN MATE i may differ from the
specifications of the operator’s manual supplied by the machine tool
builder. Be sure to read the manual provided by the machine tool
builder.
The functions of the CNC machine tool system are determined not
only by the CNC, but by the combination of the machine tool, the
power magnetic circuit of the machine tool, the servo system, the
CNC, and the operator’s panel.
It is impossible to cover all possible combinations of all functions,
programming methods, and operations in a single manual.
This manual explains only the TURN MATE i operations provided for
the CNC. For individual CNC machine tools, refer to applicable
manuals supplied by the machine tool builders.
This manual explains as many detailed functions as possible. However,
it is not possible to describe all the items which cannot be done or
which the operator must not do. Therefore, please assume that
functions not described in this manual cannot be performed.
Detailed information and special conditions are explained in notes.
The readers may encounter new technical terms in the notes not
previously defined or described. In this case, read this manual through
first, and then review the details.
NOTE
TURN MATE i has functions to support turning
cycles. This manual covers these functions
assuming that your machine has all these functions.
However, your machine may not actually be
provided with some of these functions.
Refer to the manual published by the machine tool
builder of your machine for details.
